HCB Series Belt Driven Linear Actuators of TPA ROBOT, compared with the HCR series, the HCB series driven slider with a timing belt, which means that the HCB Series Belt Driven Linear Actuators has a longer stroke and a higher speed. It is driven by a servo motor, it not only has the high precision of a servo motor but also has the advantages of high speed and high rigidity of the sliding stage itself. It is easy to control and can be easily connected with PLC and other systems. The slide actuator is made of an integrally extruded aluminum profile, with lightweight, small size and strong rigidity. The installation size and stroke can be customized according to the requirements, and the installation can be fixed by bolts. Through the combination of multiple directions, it can be formed into a linear motion system of various automation equipment, with mechanical grippers, air grippers and other fixtures, it can become an exclusive Cartesian robot or gantry robot.
HCB Series Belt Driven Linear Actuators Features
Repeated Positioning Accuracy: ±0.04mm
Max Payload: 140kg
1. Flat design, lighter overall weight, lower combination height and better rigidity.
2. The structure is optimized, the precision is better, and the error caused by assembling multiple accessories is reduced.
3. The assembly is time-saving, labor-saving and convenient. There is no need to remove the aluminum cover to install the coupling or module.
4. Maintenance is simple, both sides of the module are equipped with oil injection holes, and the cover does not need to be removed.
